Temperature And Humidity Controlled Chamber For Packaging Testing

Get a Price/Quote

Product Details:

Power Supply Electric
Operate Method Semi Automatic
Usage Testing equipment
Number of Specimens Multiple
Control Mode Manual
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Temperature And Humidity Controlled Chamber For Packaging Testing Price And Quantity

Minimum Order Quantity 1 Unit

Temperature And Humidity Controlled Chamber For Packaging Testing Product Specifications

Operate Method Semi Automatic
Power Supply Electric
Number of Specimens Multiple
Control Mode Manual
Usage Testing equipment

Temperature And Humidity Controlled Chamber For Packaging Testing Trade Information

Payment Terms Cash in Advance (CID)
Supply Ability 50 Unit Per Month
Delivery Time 10 Days
Main Domestic Market All India

Product Description

The Temperature and Humidity Controlled Chamber for Packaging Testing is a semi-automatic testing equipment that can test multiple specimens at once. This electric-powered chamber is designed to control the temperature and humidity levels within the chamber to simulate different environmental conditions and ensure the packaging materials can withstand them. The manual control mode allows for precise adjustments to be made to the testing conditions. The chamber is an essential tool for any manufacturer or supplier looking to ensure their packaging meets the necessary standards for shipping and storage.

Model	DR-H201
Temperature range	-70~+150
Temperature fluctuation	0.5
Temperature uniformity	2
Humidity range	20~98%RH (Refer Image below)
Humidity fluctuation	2.5%RH
Humidity uniformity	3%RH
Cooling speed	1/min in average (without loading)
Heating speed	3/min in average (without loading)
Internal chamber material	SUS#304 stainless steel, mirror finished
External chamber material	Stainless steel
Cooling method	Air cooling
Controller	LCD touch screen, programmable control temperature and humidity Can set different parameter for cyclic test
Insulation material	50mm high density rigid Polyurethane foam
Heater	Explosion-proof type SUS#304 stainless steel fins radiator pipe heater
Compressor	France Tecumseh compressor
Lighting	Heat resistance
Temperature sensor	PT-100 dry and wet bulb sensor
Observation window	Tempered glass
Testing hole	Diameter 50mm, for cable routing
Sample tray	SUS#304 stainless steel, 2pcs
Safety protection device	Protection for leakage Over-temperature Compressor overvoltage and overload Heater short circuit Water shortage

FAQs of Temperature And Humidity Controlled Chamber For Packaging Testing:

Q: What is the maximum number of specimens that can be tested at once?

A: This chamber can test multiple specimens at once, but the exact maximum number will depend on the size of the specimens being tested.

Q: What type of power supply is required for this chamber?

A: This chamber requires an electric power supply.

Q: Can the temperature and humidity levels be adjusted separately?

A: Yes, the temperature and humidity levels can be adjusted separately to simulate different environmental conditions.

Q: Is this chamber suitable for testing all types of packaging materials?

A: This chamber is suitable for testing a wide range of packaging materials, but it is important to check the specific testing requirements for each material.
