Compact Temperature and Humidity Controlled Box with Touchscreen & USB Data Export

28800.0 INR/Unit

Get a Price/Quote

Product Details:

Response Time <10 seconds
Port Size USB 2.0
Automation Grade Fully automatic
Measuring Range Temperature 060C, Humidity 30%98% RH
Hardness N/A (not applicable)
Resolution 0.1C / 0.1% RH
Display Type 7-inch color touchscreen
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Compact Temperature and Humidity Controlled Box with Touchscreen & USB Data Export Price And Quantity

Minimum Order Quantity 1 Unit
Price 28800.0 INR/Unit

Operating Ambient Temp. +5°C to +35°C
Insulation High-density polyurethane foam
Compliance CE, ISO certified
Data Logging Yes, internal memory & USB export
Construction Material Stainless Steel (Inner Chamber), Powder Coated Steel (Outer)
Alarm Function Over-temperature and humidity deviation alarm
Caster Wheels Yes, for mobility
Door Type Single, magnetically sealed with observation window
Internal Lighting LED illumination for chamber
Calibration Supplied with calibration certificate

Compact Temperature and Humidity Controlled Box with Touchscreen & USB Data Export Product Specifications

Control Mode Digital touchscreen controller
Humidity 30%98% RH, programmable
Test Range 0C60C | 30%98% RH
Number of Specimens 15 (variable racks)
Interface Type USB (data export), RS232 (optional)
Frequency 50Hz
Equipment Type Temperature & Humidity Controlled Box
Mounting Type Tabletop / Benchtop
Operating Voltage AC 220V 10%
Power Supply AC 220V, 50Hz
Test Width Up to 300 mm
Gas Pressure 00.6 MPa (if applicable)
Test Stroke 0200 mm
Accuracy Temperature 0.5C, Humidity 2% RH
Max Height 450 mm
Display Type 7-inch color touchscreen
Resolution 0.1C / 0.1% RH
Capacity 50 Litres
Temperature 0C to 60C, programmable
Specimen Size Up to 200 x 200 mm
Features Touchscreen, USB data export, programmable cycles, alarm system
Usage Sample storage, material aging, test simulations
Application Environmental simulation, R&D, quality control
Port Size USB 2.0
Response Time <10 seconds
Machine Weight Approx. 55 kg
Hardness N/A (not applicable)
Test Speed Adjustable 0.15 mm/min
Measuring Range Temperature 060C, Humidity 30%98% RH
Automation Grade Fully automatic

Operating Ambient Temp. +5°C to +35°C
Insulation High-density polyurethane foam
Compliance CE, ISO certified
Data Logging Yes, internal memory & USB export
Construction Material Stainless Steel (Inner Chamber), Powder Coated Steel (Outer)
Alarm Function Over-temperature and humidity deviation alarm
Caster Wheels Yes, for mobility
Door Type Single, magnetically sealed with observation window
Internal Lighting LED illumination for chamber
Calibration Supplied with calibration certificate

Compact Temperature and Humidity Controlled Box with Touchscreen & USB Data Export Trade Information

Payment Terms Cash in Advance (CID)
Supply Ability 100 Unit Per Month
Delivery Time 10 Days
Main Domestic Market All India

Product Description

Temperature and Humidity Controlled Box: Comprehensive Guide

A temperature and humidity controlled box is a specialized enclosure designed to maintain precise climatic conditions for testing, storage, or process control. Widely used in laboratories, manufacturing, and research, these systems ensure product integrity and compliance with industry standards. Below is a detailed breakdown of their functions, features, purchasing considerations, and FAQs.

Core Functions

Precision Climate Control
- Maintains user-defined temperature ranges (e.g., -20C to +80C) and humidity levels (10% to 95% RH) for sensitive materials.
- Ideal for stability testing, aging studies, or storing humidity-sensitive components like pharmaceuticals or electronics.
Cyclic Testing
- Simulates environmental cycles (e.g., day-night temperature shifts) to assess product durability.
Data Logging
- Integrated sensors record temperature and humidity data, with exportable reports for compliance audits (e.g., FDA, ISO 17025).
Contamination Prevention
- Sealed chambers with HEPA filters or inert gas purging protect samples from dust, oxygen, or microbial growth.

Key Features

High Accuracy
- Temperature stability: 0.5C
- Humidity uniformity: 2% RH
Durable Construction
- Stainless steel or anodized aluminum interiors resist corrosion and chemical exposure.
- Transparent, condensation-resistant doors for real-time monitoring.
User-Friendly Controls
- Touchscreen interfaces with pre-programmed test profiles (e.g., ICH Q1A for pharmaceuticals).
- Alerts for parameter deviations or system errors.
Energy Efficiency
- Low-power modes and eco-friendly refrigerants reduce operational costs.
Compliance
- Meets ASTM E41, ISO 9001, and GxP guidelines for regulated industries.

Purchasing Tips

Define Requirements
- Temperature/Humidity Range: Match the boxs specs to your application (e.g., cryogenic storage vs. tropical simulations).
- Chamber Size: Benchtop (550L) for small samples; walk-in for bulk storage.
Prioritize Accuracy
- For pharmaceutical or semiconductor use, opt for chambers with NIST-traceable calibration.
Evaluate Safety Features
- Over-temperature protection, backup power, and alarms for critical applications.
Check Compatibility
- Ensure the box works with external sensors or IoT platforms if integration is needed.
Assess Service Support
- Choose suppliers offering calibration services, extended warranties, and spare parts.

Frequently Asked Questions (FAQs)

Q1: What is the difference between a controlled box and an environmental chamber?
A: Controlled boxes are typically smaller, portable units for benchtop use, while environmental chambers are larger systems for industrial-scale testing.

Q2: Can these boxes simulate altitude or vacuum conditions?
A: Standard units focus on temperature and humidity. For altitude/vacuum testing, look for hybrid chambers with added modules.

Q3: How often should I calibrate the system?
A: Annual calibration is recommended, or quarterly for high-precision applications like pharmaceutical stability testing.

Q4: Are these boxes suitable for flammable material testing?
A: Only if equipped with expl

osion-proof components and ATEX/IECEx certifications.

Q5: What maintenance is required?
A: Clean filters monthly, inspect door seals for wear, and replace humidity sensors every 23 years.

Q6: Can I customize test profiles?
A: Advanced models allow custom cycles with ramp/dwell phases via USB or software.

Q7: How energy-efficient are these systems?
A: Units with inverter compressors and heat recovery reduce energy use by up to 30% compared to traditional models.

Q8: What industries use these boxes most?
A: Pharmaceuticals, electronics, food storage, and materials science.

Q9: Is remote monitoring possible?
A: Yes, IoT-enabled boxes offer cloud-based monitoring via smartphones or PCs.

Q10: What is the typical lifespan?
A: 812 years with proper maintenance, depending on usage intensity.

Internal Dimension (WHD)		400500500mm	500500600mm	500750600mm	600850800mm	10001000800mm
External Dimension (sus Type) (WHD)		95014001100mm	110015001100mm	110016701200mm	120017701400mm	155021001400mm
External Dimension (paint Type) (WHD)		70014001100mm	80015001100mm	80016701200mm	90017701400mm	155021001400mm
Temperature		-20/-40/-70
Total Power (KW)		4.5/4.5/6.5	5/5/6.5	9.5/9.5/11.6	9.5/9.5/11.6	17/17/21.5
Maximum Current (A)		25/25/32	32/32/40	25/32/40	32	50/50/60
Voltage (A)		Sigle Phase 220V		Three Phase 380V
Performane	Temp.& Humi. Adjust Way	Balanced temperature and humidity control (BTHC) PID intelligent adjustment
	Temperature Range	-20,-40,-70~150
	Temperature Accuracy	0.01
	Temperature Tolerance	1.02.0
	Temperature Fluctuations	0.5 without load and temperature stable
	Temperature Uniformity	1.5 without loading, 50mmSENSOR
	Humidity Range	20%-98%RH
	Humidity Accuracy	0.1%RH
	Humidity Tolerance	1 75%RH3%RH 2 75%RH 6%RH
	Humidity Fluctuations	2.5%RH
	Heating Rate	3/min in average
	Cooling Rate	1/min in average
Regulator	Cooling Method	Single stage compression, two stage compression
	Refrigerator	Hermertically Sealed France Tecumseh Compressor or Semi-hermetic BOcK Compressor
	Cooling Method	Air-cooled
Controller	Operation Panel	Programmable LCD Touch Screen
	Running Mode	Fix Running, Pattern Running
	Program Memory Capacity	120 Group Programmable, Max 100 Section Each
	Output	Rs-232 (USB,Optional)
Water Sup	Water Supply	Circulating Water
	Water Tank Capacity	Chamber Internal Capacity < 800L: 25L X 1pc
		Chamber Internal Capacity > 800L: 25LX 2pc

Precision Environmental Simulation

Achieve highly accurate and repeatable testing conditions for temperature and humidity with programmable cycles. This controlled box is ideal for quality control, research & development, and sample storage, offering a measuring range from 0C to 60C and 30% to 98% RH with excellent resolution and rapid response.

Advanced User Interface and Data Management

The intuitive 7-inch color touchscreen allows for easy programming and monitoring of tests. USB 2.0 data export and optional RS232 interface support efficient data logging and traceability. Internal memory ensures your testing records are always secure and accessible.

Safety, Compliance, and Ergonomic Design

Built for safety and convenience, the chamber features over-temperature and humidity deviation alarms, magnetically sealed doors with observation windows, and high-density insulation for efficient performance. CE and ISO certifications, along with supplied calibration certification, guarantee reliable operation and compliance.

FAQ's of Compact Temperature and Humidity Controlled Box with Touchscreen & USB Data Export:

Q: How does the temperature and humidity control system work in this equipment?

A: This box uses advanced sensors and a digital touchscreen controller to maintain precise temperature (0C-60C) and humidity (30%-98% RH) levels. Users can program custom cycles, and the system automatically regulates and monitors conditions for consistent, reliable testing.

Q: What is the process for exporting data from the chamber?

A: Data export is straightforward via the built-in USB 2.0 port, allowing users to quickly download environmental logs and test results. The internal memory stores data, which can be transferred to a computer for analysis or record-keeping. An RS232 interface is also available as an option.

Q: Where can this temperature and humidity controlled box be used?

A: This chamber is suitable for use in laboratories, research facilities, quality control departments, and manufacturing environments. Its compact, mobile design with caster wheels and tabletop mounting makes it versatile for various industrial and academic settings.

Q: What are the safety features included with the chamber?

A: The box is equipped with an alarm function for over-temperature and humidity deviations, a magnetically sealed door with observation window to prevent leaks, and high-density polyurethane foam insulation to maintain stable conditions. CE and ISO certifications further ensure safety and conformity.

Q: When should calibration be performed and how is it ensured?

A: Calibration is performed prior to dispatch and a calibration certificate is supplied with every unit. For continued accuracy, regular recalibration is recommended in line with laboratory standards and equipment usage frequency.

Q: What are the benefits of using LED internal lighting and observation window?

A: LED illumination provides clear visibility of the specimen chamber without opening the door, minimizing environmental disturbance. The observation window enables monitoring of the test process, ensuring experiments are undisturbed and conditions remain stable.

Q: How does this equipment improve efficiency in test simulations or material aging studies?

A: By providing programmable, precise, and stable environmental conditions, automated control, and convenient data logging, the chamber accelerates testing workflows, reduces manual intervention, and ensures high reliability in results, making it invaluable for simulation and aging studies.
