Electrodynamic Random Vibration Test Machine

Sine force (peak)

50kN

Shock force (peak)

100 kN

Frequency range

1~4000 Hz

Displacement (continuous)

100 mm

Max. Velocity

2 m/s

Max. Acceleration

100 G (980 m/s)

Armature Diameter

445 mm

1st order resonant frequency

2,400 Hz

Allowable eccentric moment

>500 Nxm

Armature weight

40 kg

HE/ST screw dimension

M10 (metric)

Axial vibration isolation frequency

<3 Hz

Max. Payload

300 kg

Magnetic flux leakage

1 mT

Dimensions (LWH, unpacked)

1,330x860x1,250 mm

Weight (unpacked)

2,500 kg

Installation

Rubber mat (anchor bolts required)

Power Amplifier (Model# VSA-H323A)

Amplifier output

30 kVA

SNR

>65 dB

Rated output voltage

120 Vrms

Amplifier efficiency

> 90%

Dimensions (LWH, unpacked)

800x900x2,100 mm

Weight (unpacked)

500 kg

Blower (Model# PBL-W30)

Air volume

0.46 m3/s

Power

7.5 kW

Air duct diameter

200 mm

Air pressure

8.8kPa

Installation

Able to connect to ceiling (up to two 90 degree bends), max 20 run

Horizontal Slip Table (Model# 30ST-600M)

Dimensions

600x600 mm

Thickness

45 mm

Frequency limit

2,000 Hz

Effective mass

54 kg

Note:

1. High pressure oil-film bearing is used for better uniformity.

Vibration Controller and Accelerometer

Vibration Controller VT-9008-4

4 Channel Vibration Controller with Sine and Self Calibration.

Accelerometer   EA-YD-181

100mV/g, Range: 50g, Working Freq.: 1-10kHz, Weight: 11gram, with 10ft low noise cable

Other supported functions/accessories

Environmental chambers

Supported

Mobile devices

Customizable

Insulation boards

Customizable

Fixture

Customizable

Working environment of the system

Temperature range

0-40

Humidity range

0~90% , no condensation

Power requirements

380V/3ph/50Hz, 40kVA

Compressed air pressure

0.6 Mpa
