altitude chamber testing ok city
548005.0 INR/Unit
Product Details:
- Port Size DN 25 mm
- Mounting Type Floor-standing
- Equipment Type Altitude Chamber
- Gas Pressure Up to 1.2 MPa
- Number of Specimens Up to 8
- Resolution 0.01 ft
- Humidity 20 95% RH
- Click to view more
X
altitude chamber testing ok city Price And Quantity
- 548005.0 INR/Unit
- 1 Unit
altitude chamber testing ok city Product Specifications
- Chamber Internal 1200 mm
- 230 V AC, 50 Hz
- 0 30,000 ft (Altitude)
- Standard 100 L
- 0.5% FS
- -70C to +180C
- Altitude Simulation 0 30,000 ft
- Altitude Environmental Simulation
- 400 mm
- Automatic / Manual
- 20 95% RH
- 0.01 ft
- Up to 8
- Floor-standing
- Altitude Chamber
- Up to 1.2 MPa
- DN 25 mm
- Max 350 mm x 350 mm
- 500 kg
- Industrial grade outer body
- 50Hz
- RS232/CAN
- < 3 seconds
- Digital Touch Screen
- Variable, up to 500 mm/min
- 0 1000 mm
- Automatic
- Environmental Simulation, Aerospace, Automotive
- 230VAC
- Temperature/Humidity/Altitude Programmable, Data Logging
altitude chamber testing ok city Trade Information
- Cash in Advance (CID)
- 100 Unit Per Month
- 7 Days
- All India
Product Description
Specifications:
| Internal dimension (W*D*H) | 1000*1000*1000mm |
| Temperature range | -70~+100(no load);-55~+100(with load) |
| Temperature fluctuation | 0.5 |
| Temperature uniformity | 2 |
| Ambient Humidity | 85%RH |
| Cooling speed | 1/min in average (with loading 15kg,+85~-55 ) |
| Heating speed | 1/min in average (with loading,-55~+85) |
| Pressure Range | 101Kpa~1Kpa |
| Pressure Accuracy | 5% |
| Pressure Control Method | Adjust temperature first, then pump vacuum |
| Internal chamber material | Steel plate with plastic spray |
| External chamber material | Stainless steel |
| Cooling method | Water Cooler |
| Controller | LCD touch screen, programmable control temperature and Pressure Can set different parameter for cyclic test |
| Insulation material | Compound material without sweating, special for low pressure |
| Heating Method | Electrical |
| Compressor | Imported new generation with low noise |
| Safety protection device | Protection for leakage Over-temperature Compressor over voltage and overload Heater short circuit |
The high-altitude climate test chamber is a testing equipment specifically designed to simulate high-altitude climate environments. It can simultaneously simulate various climate conditions such as low pressure, low temperature, low oxygen, and humidity to test the performance, reliability, and adaptability of products in high-altitude environments. It is widely used in aerospace, automotive, electronics, military, scientific research and other fields to ensure the normal operation of products in extreme environments.
Main functions
1. Low pressure simulation: Simulate a high-altitude low-pressure environment through a vacuum system.
2. Temperature control: Simulate low temperature or extreme temperature difference environments in high-altitude areas.
3. Humidity control: Simulate dry or humid environments in high-altitude areas.
4. Oxygen content regulation: Some equipment can adjust the oxygen concentration to simulate the low oxygen environment in high-altitude areas.
5. Multi environment comprehensive simulation: It can simultaneously simulate various climatic conditions such as air pressure, temperature, humidity, oxygen, etc.
Application scenarios
Aerospace: Testing the performance of aircraft, satellites, drones, and other equipment in high-altitude environments.
Automotive industry: Testing the reliability of automotive engines, batteries, electronic control systems, etc. in high-altitude environments.
Electronic products: Test the working status of electronic components, communication equipment, sensors, etc. in low-pressure and low-temperature environments.
Military equipment: Test the adaptability and durability of military equipment in high-altitude areas.
Research experiments: used for high-altitude environmental research in fields such as materials, biology, and medicine.
Technical parameters
Altitude simulation range: Typically, it can simulate altitudes ranging from 0 meters to 30000 meters (or higher).
Temperature range:- 70 C to+150 C (customizable according to requirements).
Humidity range: 0% RH to 98% RH (if equipped with humidity control function).
Pressure control accuracy: usually 1% or higher.
Oxygen concentration control: 0% to 21% (if equipped with oxygen control function).
Box size: Customized according to requirements, ranging from small desktop to large walk-in test boxes.
Select key points
1. Testing requirements: Select appropriate equipment based on the altitude, temperature, humidity, and other conditions for product testing.
2. Control accuracy: Choose high-precision air pressure, temperature, and humidity control systems to ensure the accuracy of test results.
3. Equipment size: Select the appropriate size of the test chamber based on the size of the product being tested.
4. Brand and after-sales service: Choose well-known brands to ensure equipment quality and after-sales service.
5. Customized functions: Choose whether to have oxygen control, rapid cooling and other functions according to special needs.
Ultimate Altitude Simulation
Replicate real-world extreme altitude and environmental conditions with precise control in our state-of-the-art chamber. Designed for stringent aerospace, automotive, and research needs, it enables altitude, temperature, and humidity testing from 030,000 ft and -70C to +180C. The system allows for both automatic and manual operation, enhancing flexibility while maintaining strict accuracy and safety protocols.
Advanced Engineering and Safety
The chambers interior is made from durable stainless steel 304 with a rugged powder-coated mild steel exterior for superior longevity. High-density polyurethane insulation minimizes thermal losses, while the observation window with a heating element prevents fogging. Audio-visual alarms and cam lock door with silicone gasket ensure safety and secure operation, making it a trusted choice in challenging environments.
Seamless Data Management and Operation
Equipped with a digital touchscreen control, real-time data logging, and USB export capability, managing test results is efficient and streamlined. The chamber supports automated or manual processes, variable test speeds, and quick response times (<3 seconds), providing a seamless experience for operators. RS232/CAN interface compatibility further simplifies integration into laboratory settings and quality workflows.
FAQs of altitude chamber testing ok city:
Q: How does the altitude chamber accurately simulate different environmental conditions?
A: The altitude chamber utilizes advanced sensors and programmable controls to simulate a wide range of conditions, including altitude (030,000 ft), temperature (-70C to +180C), and humidity (2095% RH). Its high precisionaccuracy of 0.5% FS and 0.01 ft resolutionensures that the programmed environment closely matches real-world extremes, making it ideal for environmental and product durability testing.Q: What is the process for conducting a test within the chamber?
A: To conduct a test, simply load up to eight specimens (max 350 x 350 mm per specimen) into the chamber, seal the cam-lock door with its silicone gasket, and use the digital touchscreen to program altitude, temperature, and humidity parameters. Tests can run in manual or automatic mode, with adjustable speeds up to 500 mm/min and strokes up to 1000 mm. Data is automatically logged and can be exported via USB.Q: When should I use an altitude chamber for my product tests?
A: Use an altitude chamber when your products or materials are intended for high-altitude environments or must be certified for resilience under rapid changes in pressure, temperature, or humidity. Its indispensable for research, quality control, and regulatory compliance in industries such as aerospace, automotive, and electronic device manufacturing.Q: Where can the chamber be installed, and what are its mounting requirements?
A: The chamber is designed as a floor-standing unit and should be installed in a laboratory or testing facility with a 230 V AC, 50 Hz power supply and appropriate venting. Its industrial-grade construction and weight (500 kg) require a stable, level surface capable of supporting its mass. The port size is DN 25 mm for easy integration with additional equipment.Q: What benefits does the built-in data logger and alarm system offer users?
A: The built-in data logger allows users to monitor and export detailed test data via USB, supporting traceability and analysis. The integrated audio-visual alarm immediately notifies operators of any test deviations, ensuring quick corrective actions and maintaining the safety and reliability of testing protocols.Q: How is humidity and temperature control maintained within the chamber?
A: The chamber uses a high-performance cooling system (air-cooled or water-cooled) and high-density polyurethane foam insulation to stabilize internal conditions. Programmable controls regulate humidity (2095% RH) and temperature (-70C to +180C), while the observation windows heating element prevents condensation that might otherwise obscure monitoring.Q: What manufacturing standards are followed for chamber construction?
A: This altitude chamber is manufactured in China by experienced exporters and suppliers using high-grade stainless steel 304 inside, powder-coated mild steel outside, and industrial-grade materials throughout. Construction prioritizes durability, safety, and compliance with international standards, making it a reliable asset in demanding laboratory settings.Tell us about your requirement
