Rapid Thermal Cycling Chamber For Battery Testing

Get a Price/Quote

Product Details:

Number of Specimens Multiple
Operate Method Semi Automatic
Power Supply Electric
Test Speed Adjustable
Control Mode Manual
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Rapid Thermal Cycling Chamber For Battery Testing Price And Quantity

Minimum Order Quantity 1 Unit

Rapid Thermal Cycling Chamber For Battery Testing Product Specifications

Test Speed Adjustable
Number of Specimens Multiple
Power Supply Electric
Operate Method Semi Automatic
Control Mode Manual

Rapid Thermal Cycling Chamber For Battery Testing Trade Information

Payment Terms Cash in Advance (CID)
Supply Ability 50 Unit Per Month
Delivery Time 10 Days
Main Domestic Market All India

Product Description

The Rapid Thermal Cycling Chamber for Battery Testing is a high-quality and reliable testing equipment designed for battery manufacturers and researchers. This chamber is equipped with a manual control mode and an adjustable test speed, allowing users to easily customize their testing parameters. It also has the capability to hold multiple specimens, making it a cost-effective solution for batch testing. This chamber is powered by electricity and operates semi-automatically, ensuring accurate and consistent test results. Its temperature range is suitable for testing various types of batteries, including lithium-ion, lead-acid, and nickel-metal hydride batteries. It can also perform temperature cycling tests, which mimic the real-life conditions that batteries are subjected to during usage. With its compact design and user-friendly interface, the Rapid Thermal Cycling Chamber for Battery Testing is an ideal equipment for battery manufacturers and researchers who require a reliable and efficient testing solution.

Model		DR-H201-100	DR-H201-150	DR-H201-225	DR-H201-408	DR-H201-1000
Internal Dimension (WHD)		500500400mm	500500600mm	600750500mm	600850800mm	100010001000mm
External Dimension (paint Type) (WHD)		75015361310mm	75016361410mm	85017861410mm	85018901710mm	125020661910mm
Temperature		-20/-40/-70	-20/-40/-70	-20/-40/-70	-20/-40/-70	-20/-40/-70
Total Powerkw		4.5/4.5/6.5	5/5/6.5	9.5/9.5/11.6	9.5/9.5/11.6	17/17/21.5
Maximum CurrentA		25/25/32	32/32/40	25/32/40	25/32/40	50/50/60
VoltageA		Sigle Phase 220V	Sigle Phase 220V	Three Phase 380V	Three Phase 380V	Three Phase 380V
Performane	Temp.& Humi. Adjust Way	Balanced temperature and humidity control (BTHC) PID intelligent adjustment
	Temperature range	-20,-40,-70~150
	Temperature accuracy	0.01
	Temperature tolerance	1.0 or 2.0
	Temperature fluctuations	0.5 without load and temperature stable
	Temperature uniformity	1.5 without loading, 50mmSENSOR
	Humidity range	20%-98%RH
	Humidity accuracy	0.1%RH
	Humidity tolerance	1 75%RH3%RH 2 75%RH 6%RH
	Humidity fluctuations	2.5%RH
	Heating rate	3/min in average
	Cooling rate	1/min in average
	Internal Chamber Material	Stainless Steel 304
	External Chamber Material	Stainless Steel steel of paint spray
Regulator	Cooling Method	Single stage compression, two stage compression
	Refrigerator	Hermertically Sealed France Tecumseh Compressor or Semi-hermetic BOCK Compressor
	Cooling Method	Air-cooled
Controller	Operation Panel	Programmable LCD Touch Screen
	Running Mode	Fix Running, Pattern Running
	Program Memory Capacity	120 Group Programmable, Max 100 Section Each
	Output	Rs-232 (USB,Optional)
Water sup	Water Supply	Circulating Water
	Water Tank Capacity	Chamber Internal Capacity < 800L: 25L X 1pc Chamber Internal Capacity > 800L: 25LX 2pc

FAQs of Rapid Thermal Cycling Chamber For Battery Testing:

Q: What is the temperature range of the Rapid Thermal Cycling Chamber for Battery Testing?

A: The temperature range of the chamber is suitable for testing various types of batteries, including lithium-ion, lead-acid, and nickel-metal hydride batteries.

Q: Can the chamber perform temperature cycling tests?

A: Yes, the chamber can perform temperature cycling tests, which mimic the real-life conditions that batteries are subjected to during usage.

Q: How many specimens can the chamber hold?

A: The chamber has the capability to hold multiple specimens, making it a cost-effective solution for batch testing.

Q: What is the power supply of the chamber?

A: The chamber is powered by electricity.

Q: What is the operating method of the chamber?

A: The chamber operates semi-automatically, ensuring accurate and consistent test results.
