Low Temperature Humidity Testing Chamber For Materials

Get a Price/Quote

Product Details:

Power Supply Electric
Number of Specimens Multiple
Usage Testing equipment
Operate Method Semi Automatic
Control Mode Manual
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Low Temperature Humidity Testing Chamber For Materials Price And Quantity

Minimum Order Quantity 1 Unit

Low Temperature Humidity Testing Chamber For Materials Product Specifications

Control Mode Manual
Power Supply Electric
Operate Method Semi Automatic
Number of Specimens Multiple
Usage Testing equipment

Low Temperature Humidity Testing Chamber For Materials Trade Information

Payment Terms Cash in Advance (CID)
Supply Ability 50 Unit Per Month
Delivery Time 10 Days
Main Domestic Market All India

Product Description

The Low Temperature Humidity Testing Chamber For Materials is a high-quality testing equipment used for testing the durability and performance of materials under extreme temperature and humidity conditions. This chamber is designed to operate manually with a semi-automatic operating method, making it easy to use and operate. The chamber is capable of testing multiple specimens at once, making it an ideal choice for industries that require high-volume testing. It is powered by electricity and requires minimal maintenance, making it a cost-effective solution for material testing. The unique feature of this chamber is that it operates at low temperatures, making it an ideal choice for testing materials that are sensitive to high temperatures. Its sturdy design and advanced features make it a reliable choice for industries such as pharmaceuticals, electronics, and automotive.

Model		DR-H201-100	DR-H201-150	DR-H201-225	DR-H201-408	DR-H201-1000
Internal Dimension (WHD)		400500500mm	500500600mm	500750600mm	600850800mm	10001000800mm
External Dimension (sus Type) (WHD)		95014001100mm	110015001100mm	110016701200mm	120017701400mm	155021001400mm
External Dimension (paint Type) (WHD)		70014001100mm	80015001100mm	80016701200mm	90017701400mm	155021001400mm
Temperature		-20/-40/-70
Total Power (KW)		4.5/4.5/6.5	5/5/6.5	9.5/9.5/11.6	9.5/9.5/11.6	17/17/21.5
Maximum Current (A)		25/25/32	32/32/40	25/32/40	32	50/50/60
Voltage (A)		Sigle Phase 220V		Three Phase 380V
Performane	Temp.& Humi. Adjust Way	Balanced temperature and humidity control (BTHC) PID intelligent adjustment
	Temperature Range	-20,-40,-70~150
	Temperature Accuracy	0.01
	Temperature Tolerance	1.0or2.0
	Temperature Fluctuations	0.5 without load and temperature stable
	Temperature Uniformity	1.5 without loading, 50mmSENSOR
	Humidity Range	10%-98%RH
	Humidity Accuracy	0.1%RH
	Humidity Tolerance	1 75%RH3%RH 2 75%RH 6%RH
	Humidity Fluctuations	2.5%RH
	Heating Rate	3/min in average
	Cooling Rate	1/min in average
Regulator	Cooling Method	Single stage compression, two stage compression
	Refrigerator	Hermertically Sealed France Tecumseh Compressor or Semi-hermetic BOcK Compressor
	Cooling Method	Air-cooled
Controller	Operation Panel	Programmable LCD Touch Screen
	Running Mode	Fix Running, Pattern Running
	Program Memory Capacity	120 Group Programmable, Max 100 Section Each
	Output	Rs-232 (USB,Optional)
Water Sup	Water Supply	Circulating Water
	Water Tank Capacity	Chamber Internal Capacity < 800L: 25L X 1pc
		Chamber Internal Capacity > 800L: 25LX 2pc

FAQs of Low Temperature Humidity Testing Chamber For Materials:

Q: What is the control mode of the Low Temperature Humidity Testing Chamber For Materials?

A: The control mode of this chamber is manual.

Q: How many specimens can be tested at once in this chamber?

A: This chamber is capable of testing multiple specimens at once.

Q: What is the usage of this chamber?

A: This chamber is used as testing equipment for materials.

Q: What is the power supply required for this chamber?

A: This chamber is powered by electricity.

Q: What is the operating method of this chamber?

A: The operating method of this chamber is semi-automatic.
